L05-Spherical-Head Tilt-Up Anchor
Tilt anchor particularly designed to convert precast concrete architectural pieces from a horizontal to a vertical plane. By ensuring there is no contact between the ring clutch and the concrete surface, the innovative head design completely eliminates the possibility of aesthetic harm to the concrete finish. Used in sandwich panel production.
SPECIFICATIONS
* Safety Factor is 3:1.
* Stainless Steel 304 (A2)/316(A4) are available according to the request.
* Surface Black /Zinc Plate (Z.P) / Hot Dipping Galvanizing (H.D.G) are available.
Rated Load/Tons Code L(mm) D1 (mm) D (mm) 2.5 L05-025 240 26 14 5 L05-050 240 36 20 The spherical head pitching anchors are used to tilt and lift thin concrete wall or beam elements. They are especially suitable if a tilt-up table is not used for production. The universal head lifting link can be used for this anchor head as the head design is identical to the spherical head anchor.
